buy hospital medical supply bedside table for sale - Bulk Supply and Specification Guide
Scope of Supply and Physical Form
| Parameter | Specification |
|---|---|
| Overall dimensions (W × D × H) | 800 mm × 400 mm × 750‑950 mm (adjustable) |
| Tabletop material | High‑pressure laminate (HPL) 12 mm, edge banded |
| Frame material | Powder‑coated steel tube 30 × 30 mm, 2 mm wall |
| Caster type | Four 75 mm twin‑wheel, two locking, two swivel |
| Load capacity | 120 kg static, 80 kg dynamic |
| Height adjustment range | 200 mm pneumatic lift, 10 mm increment |
| Finish | Epoxy‑polyester powder coat, 80 µm, antimicrobial additive |
| Packaging (per unit) | Corrugated carton 860 × 460 × 820 mm, 22 kg gross |
| MOQ | 50 units |
| Lead time (after sample approval) | 35‑45 days |
The tabletop uses a 12 mm HPL core that resists impact and chemical cleaning agents. The steel frame’s 2 mm wall thickness yields a first‑mode natural frequency above 12 Hz, reducing vibration when a monitor arm is mounted.
Height adjustment relies on a sealed pneumatic cylinder rated for 100 000 cycles; the 10 mm increment allows precise alignment with bed frames without tools.
Buying Mistakes That Lead to Returns
Specify the exact caster lock orientation in the drawing; a 90° mismatch forces the wheel to bind under load and triggers early bearing failure.
Buyers often select a 100 kg static rating for a ward that routinely holds 130 kg of equipment, causing frame deflection beyond the 5 mm tolerance.
- Overlooking the antimicrobial additive in the powder coat leads to surface staining after repeated chlorine wipes.
- Ordering a fixed‑height model for a facility that uses variable‑height beds creates ergonomic complaints within weeks.
- Skipping the pre‑shipment drop test on a pallet of 10 units results in cracked edge banding on 3‑5 % of the lot.
A documented sample approval that includes a 48‑hour salt‑spray exposure and a 500‑cycle height‑adjustment run eliminates most of these returns.
Usage Scenarios and Buyer Segments
Standard Fixed‑Height
Tabletop height 750 mm, no lift cylinder.
Load capacity 120 kg static.
Best for long‑term care rooms with uniform bed height.
Height‑Adjustable Central Lock
Pneumatic lift 200 mm range, 10 mm steps.
Load capacity 80 kg dynamic.
Suited for acute wards with electric beds.
Hospital procurement teams typically order the adjustable version for ICU and step‑down units, while distributors serving nursing homes favor the fixed model for its lower unit cost and simpler maintenance.
Inspection Items and Test Methods
| Usage Level | Static Load Test | Cycle Test (height adjust) | Salt Spray (hours) | Caster Roll Test (m) |
|---|---|---|---|---|
| Light (clinic) | 100 kg 5 min | 20 000 cycles | 200 | 500 |
| Medium (ward) | 120 kg 10 min | 50 000 cycles | 500 | 1 000 |
| Heavy (ICU) | 150 kg 15 min | 100 000 cycles | 1 000 | 2 000 |
Each production lot undergoes a first‑article inspection that records dimensional deviation, coating thickness, and caster torque. The data are logged to the batch traceability sheet shipped with the carton.
Capacity, Tooling and Scheduling
The line runs two parallel welding cells, each capable of 120 frames per shift. Powder‑coat booth capacity is 300 parts per day, which sets the practical ceiling for a 500‑unit order at roughly four weeks after tooling release.
- Tooling for the pneumatic cylinder mount requires a 3‑week lead time; the cylinder itself is a catalog item with 1‑week availability.
- Artwork for private‑label silk‑screen on the tabletop edge must be supplied as vector AI at 300 dpi; approval adds 5 business days.
- Sample approval package includes a full‑size dimensional report, a 48‑hour salt‑spray coupon, and a 10 000‑cycle lift test video.
Expedited schedules are possible by overlapping cylinder procurement with frame welding, but the powder‑coat cure window remains the bottleneck.
Setup, Use and Replacement Parts
Assembly requires a 5 mm hex key for the four caster bolts and a 13 mm spanner for the cylinder lock nut; no specialized tools are needed.
Caster wheels are interchangeable across the product line; a single SKU covers both locking and swivel variants, reducing spare‑parts inventory to one line item.
Tabletop replacement follows a 15‑minute procedure: remove the four corner brackets, lift the HPL panel, and reinstall. The brackets are torqued to 6 Nm to maintain the 5 mm flatness tolerance.
Ready to finalize a spec? Share your drawing package and target MOQ; we will return a detailed quotation within 48 hours. Request a quote
